Chint DTSU666-H Three-Phase Meter with External CTs Included – Measurement up to 250A
Three-phase measuring device designed for advanced energy monitoring in photovoltaic systems.
Enables precise measurement of energy consumed and fed into the grid up to 250A.
Compatible with Huawei inverters for intelligent energy flow management.
Real-time monitoring via the Huawei FusionSolar system.
Easy installation thanks to the included external current transformers (CTs).
Main Features
Measures active and reactive energy with high precision.
Compatible with Huawei inverters for optimized energy production and consumption management.
RS485 (Modbus RTU) communication for connection to the monitoring system.
Supplied with external CTs up to 250A for easy installation on large-scale power systems.
Suitable for commercial and industrial photovoltaic systems.
Show more...
Technical Data
- Type: Three-phase meter
- Model: Chint DTSU666-H
- Power supply: 3x230/400V AC
- Maximum measurable current: 250A
- Communication interface: RS485 (Modbus RTU)
- Accuracy: ±1%
- Display: LCD for real-time data viewing
- Compatibility: Huawei inverters and FusionSolar system
- Installation: DIN-rail
- External CTs: Included up to 250A
- Operating temperature: -25°C ~ +60°C
- Protection rating: IP51
- Weight: 0.6 kg
